TCF100 - 100A Cube Fuse

Eaton

$281.21 (Each)
$281.21 (Each)
$1,687.26 (Per 6)

Availability: Currently Out Of Stock

Buy Now

QTY:

Each

Overview
Specifications
Current Stock
Alternate Items

Overview

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Close

Help Improve Our Data

Quick Specs

Catalog Number: TCF100 Vendor Code BUS
Manufacturer: Eaton
Manufacturer's Part Number: TCF100
Description: 100A Cube Fuse
Eaton Bussmann Series Class CF Fuse, TCF, Time-Delay, Dual-Element Current Limiting Cube Fuse, 100 A, Indicating Fuse, Interrupting Rating Of 100 Ka At 300 VDC and 300 Ka At 600 Vac
Slang Terms: Suggest a New Term
Categories: Enhanced Commodity Codes - Tools & Testers Mark as Incorrect
Suggest a New Category
Classification: Fuses & Fuse Accessories
UNSPSC: 39121606 - Cartridge fuses
UPC/EAN/GTIN: 051712618182 / 5027590244091 / 00051712618182
Weight per unit: 0.129 (lbs/each)

Price & Packaging

Minimum Order Quantity: 1
Unit: $281.21 (Each)
Standard Packaging: $1,687.26 (Per 6)

Resources

Other Links
: TCF100 - Other
: TCF100 - Other
: TCF100 - Other
: TCF100 - Other
Brochures
: TCF100 - Brochure
Attachments
: TCF100 - Specification Sheet
Images
: TCF100 - Large Image
: TCF100 - Large Image
: TCF100 - Large Image
: TCF100 - Small Image
: TCF100 - Video

Suggest Substitute Item

Help Improve Our Data

Edit Mode: Please login to suggest improvements for this item.

Close

Specifications

Thank you for your suggestions! We appreciate your assistance in improving our software. It helps us serve you even better!

Edit Mode: Please login to suggest improvements for this item.

Close

Help Improve Our Data

Features

connection: Blade End
Material: Glass Filled PES
amperage rating: 100 A
interrupt rating: 100 kAIC at 300 Vdc300 kAIC at 600 Vac
Voltage Rating: 600 Vac, 300 Vdc

Dimensions and Weight

Size: 3.01 In Length X 1.00 In Height

Descriptions

Description: 100A CUBE FUSE
Features: The revolutionary BussmannTM series Low-PeakTM CUBEFuseTM delivers the smallest footprint compared to any Class CC, J or RK fuse solution — requiring up to 70 less space when combined with its unique fuse holder or UL 98 Listed Compact Circuit Protector switch. Freeing up space is powerful. And the CUBEFuse does just that, while packing up to a 300 kA interrupting rating and enabling higher equipment short-circuit current rating (SCCR). Available from 1 to 400 amps.
Product Type: Cubefuse 100 Amp
extra long description: EFSE TCF100 CUBEFUSE 100 AMP
Long Description: Eaton Bussmann Series Class CF fuse, TCF, time-delay, dual-element current limiting cube fuse, 100 A, indicating fuse, interrupting rating of 100 kA at 300 Vdc and 300 kA at 600 Vac
Special Features: Finger Safe

Additional Information

media: Yes
class: Class CF
element: Dual
type of indicators: Energetic Chemical Open Fuse Indicator
Response Time: 10 S at 500%
dimensions: 3.0100 IN X 1.0000 IN X 2.1250 IN

Manufacturer Information

Manufacturers Part Number: TCF100
Brand: Eaton
GTIN: 00051712618182
UPC: 051712618182

Taxonomies, Classifications, and Categories

Category Description: Fuses & Fuse Accessories
Type: FUSE

Packaging

Weight per each: 0.129
Carton: 1
Package: 6

Uses, Certifications, and Standards

standard: CSA Certified,UL Listed,CE Marked,RoHS Compliant
Application: Ind Facilities & Factories - Facility: Safety and Security SystemsDatacenters - Facilities: Power DistributionCommercial / Institutional Buildings / Structures - Critical PowerInd Facilities & Factories - Facility: Power Distribution and ControlStationary Machinery and Equipment Outside Factory - HVAC
Mounting: 35 mm DIN Rail, Chassis
